The Shuttle S-DC-DIM-96W is a compact 9V to 48V DC LED dimmer designed for constant-voltage lighting systems that need smooth, reliable control. It is a practical solution for LED strips, modules, and other DC lighting setups where low-light ambience and precise dimming are important.

This bell-press dimmer is built for flexibility, with digital control, no minimum load, and compatibility across a wide DC operating range. It is suitable for a variety of installs, including custom lighting projects, vehicles, caravans, boats, and other 12V, 24V, or 48V DC applications.

Specifications

• SKU: LUM-S-DC-DIM-96W
• Original SKU: S-DC-DIM-96W
• Model: DC-LED-96W
• Product Type: Dimmer Module
• Operating Voltage: 9VDC to 48VDC
• Maximum Load Power: 96W
  • Maximum Load Current: 8A @ 12VDC
  • Maximum Load Current: 4A @ 24VDC
  • Maximum Load Current: 2A @ 48VDC
• Dimming Method: Digital (10-bit)
• Dimming Range: 0.7% to 99.9%
• Minimum Load: No minimum load
• Control: Bell-press
• Memory: Retains previous dimming level
• Protection: Reverse polarity, brown-out, overload, and surge protection
• Operating Temperature: -5°C to +40°C
• Enclosure: 36 x 36 x 12 mm plastic
• Designed and Manufactured: South Africa
