4 Pole 63A 30mA Residual Current Circuit Breaker (RCCB) – Type AC
This 4-pole Residual Current Circuit Breaker (RCCB) is designed to provide reliable protection against earth leakage and electric shock in residential, commercial, and industrial electrical systems. Built to IEC standards, it ensures safety by automatically disconnecting the circuit when leakage current is detected.
With a rated current of 63A and a 30mA sensitivity, this RCCB offers high-level protection for people and equipment. Its robust design supports flexible installation and compatibility with auxiliary components, making it a dependable choice for modern electrical distribution systems.
Practical Tip: Install RCCBs with 30mA sensitivity on circuits supplying sockets and wet areas to ensure optimal protection against electric shock.
Key Features
- 4 pole RCCB for complete circuit protection
- 63A rated current with 30mA sensitivity
- Type AC for standard residual current protection
- High electrical and mechanical endurance
- Double connection terminals (top and bottom)
- Compatible with auxiliary devices and restart systems
- Suitable for a wide range of installations
Specifications
- Device Type: Residual Current Circuit Breaker (RCCB)
- Code: IDP
- Poles: 4P
- Module Size: 4 Modules
- Rated Current: 63A
- Rated Residual Current: 30mA
- Type: AC
- Rated Voltage: 400/415V
- Frequency: 50/60Hz
- Insulation Voltage (Ui): 500V
- Impulse Withstand Voltage (Uimp): 4kV
- Overvoltage Category: III
- Immunity (8/20μs): 250A
- Cable Size (Rigid): ≤1×35 / ≤2×16 / ≤1×16+2×10 mm²
- Cable Size (Flexible): ≤1×35 / ≤2×16 / ≤1×16+2×10 mm²
- Tightening Torque: 3 Nm
- Connection Type: Double (upstream & downstream)
- Operating Temperature: -25°C to +60°C
- Storage Temperature: -40°C to +70°C
- Electrical Endurance: ≥10,000 operations
- Mechanical Endurance: ≥20,000 operations
- Auxiliary Compatibility: Yes
- Restart Compatibility: Yes
- Mounting Position: Any
- Standards: IEC/EN 61008-1, IEC/EN 61008-2-1
- Tariff Code: 85362010
- IP Rating: IP20 – Indoor Use
Ideal Applications
- Distribution boards
- Residential electrical systems
- Commercial installations
- Industrial control panels
- Circuits requiring earth leakage protection
Why Choose This RCCB
- ✔ Reliable protection against electric shock
- ✔ High durability and long operational life
- ✔ Flexible installation with broad compatibility
Read Product Guidelines
Begin by reading the product manual provided to understand the breaker’s functionalities.
Ensure Power is Off
Turn off the power supply to the circuit where installation will occur for safety.
Mount the Device
Place the Residual Current 4 Pole Circuit Breaker into the electrical panel securely.
Connect the Wiring
Link the appropriate wires to the breaker, following circuit diagram instructions closely.
Test the Setup
Switch the power back on and test the breaker to ensure it functions correctly.
What is the primary function of this circuit breaker?
The breaker protects electrical circuits against residual currents, thus preventing potential hazards and ensuring safety.
Can it be used in outdoor settings?
This breaker is designed for indoor use with an IP20 rating, requiring a protective enclosure if used outdoors.
Does the unit require maintenance?
Regular inspections are recommended to ensure functionality, but the device itself requires minimal maintenance.
Is it compatible with renewable energy systems?
Yes, the breaker can be integrated into renewable energy systems for enhanced safety and protection.
What does the 4 pole configuration mean?
The 4 pole breaker provides protection for three-phase circuits, including a neutral line.
